ZGS13-H American-Style Combined Substation

American-style (pad-mounted) combined substation integrating HV load-break switch, fuse protection and transformer in a compact sealed tank.

Voltage Class	up to 12 kV
LV Voltage	0.4 kV
Transformer	Oil-immersed, sealed (S11 / S13)
Capacity	up to 2500 kVA
Type	Pad-mounted, sealed
Standards	GB/T 17467 / DL/T 549

✓ Backed by a 12-month warranty.

Key Features

Compact pad-mounted sealed design.
Integrated HV switch + fuse + transformer.
For residential, commercial and industrial sites.
Low maintenance, weatherproof.

Configure Your Substation

An American-type (pad-mounted) substation is a single compact assembly: the HV switching, fuse protection and transformer share one oil-filled tank, with the oil serving as both insulation and arc-quenching medium. Each module below is specified to your project. Tell us your requirement (e.g. ring-network feed + 800 kVA + tropical rating) and we build to it.

Section 1

HV Switching

Four-position load switch + backup & plug-in fuses.

Section 2

Transformer (in oil)

Sealed oil-immersed core, oil = insulation & arc-quench.

Section 3

LV Side

Metering, distribution and compensation to spec.

Feed Configuration

Choose

Terminal / radialRing-network (loop-through)Dual-source

HV Switching & Protection

Choose

Four-position load switchTwo-position load switchBackup current-limiting fusePlug-in fuse

Transformer

Choose

Oil-immersed sealed (S11 / S13)

150–1600 kVA, 10/0.4 kV, oil self-cooling (AN). Tap range ±5% or ±2×2.5%.

Bushing Interface

Choose

Dead-front (elbow connectors)Live-front

LV Side

Configure

Distribution + meteringReactive-power compensationControl & monitoring

Options & Climate

Option

Prepayment meteringSurge arrestersStandard climateHigh-altitude (>1000 m)Tropical / coastal

Standard configuration is highlighted in amber. Any combination is available on request — send us your single-line diagram (SLD) or load schedule and our engineers will confirm the build and price. Start a configuration →
